Automotive wheel bearing is an essential component of the vehicle. It transmits engine power into wheels and supports vehicle weight. In recent years, the demand worldwide for weight reduction in automotive part in order to improve fuel efficiency has increased. Despite of it, automakers are requiring that wheel bearing performance in the areas of stiffness, strength, and life be maintained or improved. In this study, weight optimization for automotive wheel bearing was performed. Design variables were the bearing geometry and bearing internal specification. Cost function was bearing weight and constraint conditions were bearing life and stiffness. CATIA was used to model the geometry and Abaqus was used to carry out the stiffness analysis. To construct the optimization formulation, the commercial optimization software, Isight was used.

Customer Papers

S-Life - Integrated Static and Fatigue Strength Assessment with Abaqus According to German FKM Guideline

Customer Papers

The traditional process for assessing the strength, stiffness and modal performance of a chassis component such as a suspension link, and iterating the design to meet targets in the optimum way, is time consuming. Some design engineers experimented with using integrated analysis in CATIA V5 to assess and iterate the design more efficiently. Success was limited due to the complexity of setup and poor correlation with the results obtained by CAE specialists using the standardised process. This paper outlines how a combination of CATIA V5 analysis and scripting was used to solve these problems for a number of component types. The success of the tools released to date and the advantages of using them will be discussed. Guidelines for identifying processes which are suitable for automation will be presented.

Customer Papers

Materials Gateway 3.0 for Abaqus/CAE - Enterprise-wide Materials Knowledge for Abaqus Users

Customer Papers

In the deep drawing tools for forming car body parts, heavy blankholders are used to prevent buckling and wrinkling of the blank. During each press cycle, those large masses need to be lifted, raising thereby the structural dynamic load on the deep drawing tool and on the press. Therefore a detailed knowledge about the blankholder’s lift-off event is essential for an accurate and robust design of forming tools. In this paper, a dynamic finite element method (FEM) simulation of a blankholder’s lift-off in a selected automotive deep drawing tool is presented enabling identification of regions of critical stresses. The FEM model is built within the Abaqus/CAE environment and solved with Abaqus/Standard.

Customer Papers

Peen-forming is a practical technique for forming of metallic aeronautical components. The method performance of this cold-working procedure mainly depends on the efficient selection of process parameters. Currently, trial and error procedures, based on operators' experience are used to determine peen-forming intensity patterns. This expensive and time consuming method could be avoided by the accurate estimation of peen-forming process parameters. The absence of a predictive tool to determine these parameters makes difficult to give a quick response to market for the industrialization of new components.

Customer Papers

This research work aims at modeling the mortar-block assembly for analyzing the potential occurrence of mechanical problems at interfaces as the consequence of an eventual incompatibility. The study considers a heritage building located in Morocco. The authors focus their attention on a representative part of the building and perform numerical simulations, studying the stress repartition inside the masonry. For carrying out efficient analysis, the mechanical characteristics (Modulus of Resistance, Modulus of Elasticity) are collected through non-conventional testing techniques dedicated to the field of Heritage Conservation that are briefly described. The scenario considered in the proposed study concerns a bearing wall restored with a non-adequate mortar. The goal of the modeling works is to compare the repartition of internal solicitations between the original situation and the restored one in order to quantify the risk, for materials that should be conserved, associated with the “stress shielding” phenomenon and to justify the particular attention to be paid for the choice of a specific mortar for interventions to be carried out on the concerned building.

Customer Papers

The use of a stitched triaxial fabric in composite forming applications is investigated. The fabric of interest consists of three layers of stitched fibers, which were originally oriented at [-60°/0°/60°]. The tensile, shear, and frictional behavior was investigated experimentally. Conventional shear frame testing methodology assumes that the yarns are intially mutually perpendicular. This assumption is not valid for this particular fabric geometry and must be adjusted accordingly. The determined material behavior was implemented into a user-defined material subroutine within a discrete mesoscopic finite element model built in Abaqus/CAE. Different element types were investigated to represent the fabric and determine ideal mesh configurations to best capture the mechanical behavior of the fabric.

Customer Papers

The purpose of this paper is to make an improved concrete damage plasticity model that focus on a post cracking behavior. First, we constitute the material model that simulates a process of closing the large tensile cracks and recovering the compression stiffness. Second, the model is enhanced by adding another feature that simulates a transition from compression to tension again. Finally, experimental simulation analyses are conducted for validation of efficiency.

Customer Papers

By using Abaqus finite element software, contributions to understanding and quantifying the ductile fracture behavior of metallic materials have been realized. The end result has enhanced product development by reducing unnecessary conservatism resulting in reduced failure rates, product weight, and costs. Unlike the methods of LEFM or EPFM which presume a preexisting flaw, the ductile fracture approach requires no initial flaw size, shape, or flaw orientation relative to the component geometry. In this paper, numerical examples using various damage approaches are used to highlight differences in their resulting failure modes. In addition, the use of a damage model on a practical example is used to emphasize the utility of the method.

Customer Papers

Carbon fiber reinforced materials are getting widely spread. But at present time method of the calculation of impact residual strength for carbon fiber parts is poorly developed. Especially this method is underdeveloped in case of the delaminated composite parts. Residual strength is very essential for any project where the composite material parts are used. The possibility to estimate the value of residual strength of the carbon fiber reinforced parts is highlighted in terms of safety for Aerospace structures. In this work we propose a method to calculate the carbon fiber panel residual strength of the civil plane wing prototype with respect to delamination progress simultaneously with degradation law of the material properties. This approach has been developed and realized based on ABAQUS software.

Customer Papers

During the manufacturing of fabric-reinforced composite parts using a matched-die compression molding process or resin transfer molding, the fabric may experience local in-plane compressive loads that cause out-of-plane deformations. The waves that form from such out-ofplane motion can result in resin-rich pockets (during the infusion stage of a dry fabric) or the waves may be forced down into a fold by the tooling. Such defects can compromise the structural integrity of the formed composite part. A comparison of the simulation results to the experimental data shows the finite element model accurately captures this phenomenon. An additional model is presented to demonstrate the capability of the simulation tool to capture fabric folding.
