The mechanical methods used to extract virgin oils from olives are of two types: the discontinuous system and the continuous system. In any case, the system defined as "continuous" is composed of several steps, not all of which are completely continuous, due to the presence of the batching device. The aim of this work was to design a prototype of a home olive oil extraction machine with a heating device to be placed immediately before the filtration step to facilitate solid / liquid separation. This strategy represents the first step towards the transformation of the step of mixing a discontinuous operation into a continuous real process. The design, analysis and simulation were done using Catia and Abaqus.

Customer Papers

This research work study the modeling the mortar-block assembly for analyzing the potential occurrence of mechanical problems at interfaces as the consequence of an eventual incompatibility. The study considers a heritage building located in Morocco. In this recent study the authors test the effect of non linear behavior of materials and interface. The goal of the modeling works is to compare the repartition of internal solicitations between the original situation and the restored one in order to quantify the risk, for materials that should be conserved, associated with the “stress shielding” phenomenon and to justify the particular attention to be paid for the choice of a specific mortar for interventions to be carried out on the concerned building. One concrete numerical example using Abaqus code will be treated and showed on this paper.

Customer Papers

Engineering analyses are often targeted to help design parts and systems that provide a margin of safety against failure. More sophisticated models that include plasticity, damage, and failure help the analyst assess the part or system’s ability to continue to serve its intended function safely in a partially-damaged state. However, at Kimberly-Clark we like failure—specifically when consumers are tearing a paper towel off the roll (known as “dispensing” in the parlance of consumer packaged goods). By utilizing Abaqus, the essential roles the mechanical behavior (including failure) of the towel and the perforation pattern have in dispensing has become clearer.

Customer Papers

Permanent set in applications using rubber is a common problem. Modeling of this phenomenon is available in the literature; however, the permanent set material models are not widely used because of their limitations and lack of validation. Recently, one permanent set model was implemented using Abaqus. To validate this model in actual applications, it was assessed through a series of button compression set tests at three temperatures. The sensitivity of the permanent set model to multiple hyperelastic models was studied. Some minor issues were observed in the application of the model with regard to field temperature, and a workaround solution was identified. The model was otherwise verified and validated through compression set test results.

Customer Papers

The flow behavior of fiber filled material systems is of interest in polymeric composites processing. Specifically, applications such as injection molding and compression molding are concerned with determining the final fiber orientation state. As applications move towards increased fiber length and volume fractions seeking enhanced mechanical performance, significant anisotropy is introduced in the viscous response during processing. However, commercially available tools for molding simulation do not account for strongly coupled anisotropic flow. A method is presented in which Abaqus/Standard and Abaqus/Explicit are utilized to perform coupled anisotropic viscous flow simulation and fiber orientation analysis using a developed UMAT and VUMAT respectively.

Customer Papers

Topology optimization is a powerful method in the field of manufacturing, but currently lacks any sort of guiding workflow. This paper introduces a first iteration workflow for using topology optimization as a design method within a digital manufacturing framework. Unlike traditionally designed and machined parts, topology optimized and additively manufactured parts lack definitive standards for processing and qualification. Content will cover advantages, challenges, and best practices for using topology optimization as a design method for additive manufacturing. As additive manufacturing and topology optimization technologies mature, new design workflow processes, similar to those described in this paper, will become more standardized and accepted within engineering industries.

Customer Papers

The transient temperature distribution of a quenched solid is driven by the convection coefficient at the wetted interface and the temperature difference between the component and quenching fluid. During finite element analysis, accurate applications of the convection coefficient is especially difficult due to the temporal evolution of the coefficient during the quenching process. For example, excursions through multiple regimes such as nucleate boiling followed by turbulent and/or laminar thermal boundary layers are common. During simulation efforts, a constant-valued coefficient is often used in lieu of the dynamic coefficient that accurately represents the convective boundary.

Customer Papers

Packaging trends indicate that the consumer is demanding not only a visually appealing package but also one that has a functional benefit after purchase. Challenges to that outcome include adequate top load and dent resistance at the lightest possible weight. Products like ketchup, mayonnaise, salad dressing, dish and hand soap are a few types that need to meet these performance characteristics. This study examined existing commercial packages and analyzed the design features that can be modified to improve container squeezability. These geometric features involve structural components like ribs in the panel area and also the vertical and horizontal profile of the container design.

Customer Papers

Abaqus can be used to simulate welding processes, but the procedure can be time consuming due to a large number of steps necessary to generate weld beads and the associated thermal loads and convective film interactions. Recent development of the Abaqus Welding Interface (AWI) addresses these challenges, as the AWI utility automatically creates all of those steps. While the AWI procedure is quite straightforward, its accuracy can be expected to be highly dependent on the magnitude of several parameters defined in AWI: torch temperature, temperature ramping option, and deposited weld “chunk” length. This paper presents a sensitivity study of temperature fields to these parameters using a case study of a T-joint fillet weld.

Customer Papers

Additive manufacturing, specifically the extrusion deposition process, involves the progressive addition of material at elevated temperatures following a prescribed machine path at prescribed speed. Utilizing the newly available features of Abaqus 2017, specifically element activation and event series, progressive element activation is performed by implanting the user subroutine UEPActivationVol. In this work, the system at Purdue University for extrusion deposition of highly filled, high temperature thermoplastics is modeled through a user subroutine suite which coordinates element activation according to machine instructions, assigns appropriate local coordinate systems for using anisotropic material properties, and sets relevant initial state variables for user material models.

Customer Papers

A multiphysics simulation capability has been developed that incorporates mutual interactions between aerodynamics, structural response from aerothermal loading, ablation/pyrolysis, heating, and surface-to-surface radiation to perform high-fidelity, fully coupled aerothermoelastic ablation simulations, which to date had been unattainable. The multiphysics framework couples CHAR (a 3D implicit charring ablator solver), Loci/CHEM (a computational fluid dynamics solver for high-speed chemically reacting flows), and Abaqus/Standard to create a fully coupled aerothermoelastic charring ablative solver.

Customer Papers

The eXtended Finite Elements Method (XFEM) refers to a simulation technique where a fracture is modeled via splitting of special enriched finite elements during the course of a simulation. XFEM, unlike Cohesive Zone Method (CZM), allows simulating nucleation and growth of a fracture along an arbitrary, solution-dependent path without re-meshing the material in the bulk. In this work, we have used 2D XFEM coupled with pore-pressure degrees of freedom to simulate a variety of boundary value problems related to fluid-driven (hydraulic) fractures in a permeable medium. Specifically, through these simulations, we investigate the influence of critical geomechanical and operational parameters on hydraulic fracturing.
