Material Efficiency in Industry

Material usage optimization has become the cornerstone of the transformation that the industry is currently experiencing. Manufacturers relentlessly pursue lightweight and robust components to deliver cost-efficient production with lower warranties, minimal recall costs, and accelerated timelines. Advanced finite element analysis is a staple in design stress calculations. Many companies still rely on manual stress point selection for spreadsheet analysis to conduct fatigue analysis. This approach is time-consuming and unreliable because it increases the risk of overlooking critical failure locations.

FEA Fatigue Analysis

fe-safe is the technical leader in fatigue analysis software for finite element models. fe-safe has set the benchmark for fatigue analysis software since the early 1990s in close collaboration with the industry. The fe-safe software suite is a world-leading technology for durability analysis from FEA. It directly interfaces with all major FEA suites (Abaqus, ANSYS, Nastran) and can meet the most demanding industry applications.

Fatigue Analysis Methods

fe-safe was the first commercially available fatigue analysis software to focus on modern multiaxial strain-based fatigue methods and it continues to set the benchmark for fatigue analysis software. Extended Packaging includes fe-safe, allowing unified access to all solution technologies within the portfolio through a single token pool. fe-safe is popular for its accuracy, speed, comprehensive capabilities and ease of use. Regardless of the complexity of your fatigue analysis, fe-safe fits smoothly into your design process, enabling you to develop durable products.

Fatigue Analysis Software

The fe-safe suite provides:

  • fe-safe: Accurate, reliable multiaxial fatigue analysis, regardless of the complexity of your loadings and model
  • fe-safe/Rubber: Unique, leading-edge technology for the fatigue analysis of elastomers
  • Verity Module in fe-safe: The original, patented Verity™ Structural Stress Method for seam, structural and spot-welded joints
  • Smooth workflow between the SIMULIA portfolio of products: Abaqus, Isight and Tosca

fe-safe At a Glance

  • Calculates fatigue lives at every point on a model, producing contour plots to reveal fatigue lives and crack sites without missing critical locations.
  • Determines the intensity of stress change required to achieve a target design life. It highlights clearly where the component is under strength and opportunities to save material and weight.
  • Estimates warranty claim curves based on probabilities of failure.
  • Identifies which parts of a duty cycle are most damaging. In prototype testing, this could mean shorter tests with fewer actuators.
  • Accounts for manufacturing effects such as residual stresses from a stamped or formed part,  surface finishes, or the material variation effects in castings and forgings.
  • Automatically detects triaxial stress states, e.g. due to contact, to use more extensive critical plane search
  • Requires no special meshing, allowing for solid and shell elements in the same model.
  • Offers fast random vibration fatigue analysis in the frequency domain via single-channel or multi-channel loading PSDs/CSDs with multi-axial critical plane analysis.
  • Verity in fe-safe includes a unique calculation of the fatigue life of welded joints using the patented VerityTM Structural Stress Method.  It can be used with multi-channel PSD/CSD loading.
  • fe-safe/Rubber includes a unique technology for fatigue of elastomers using state of the art elastomer-specific algorithms.
  • In addition, test signal processing functions and strain gauge fatigue algorithms are included in fe-safe standard.

Discover the Modules

Durability Analysis Software for Finite Element Models
Durability Analysis Software for Finite Element Models
Verity™ Module in fe-safe
Durability Analysis Software for Finite Element Models

Start Your Journey

Explore the technological advancements, innovative methodologies, and evolving industry demands that are reshaping the world of Durability Analysis and Finite Element Analysis. Stay a step ahead with SIMULIA. Discover fe-safe now.
