Antenna Magus is the most extensive antenna synthesis tool available today.

It supports over 350 antenna types, which can be designed to meet the system criteria and exported to integrate seamlessly with your design workflow. Many additional tools and utilities useful for efficient antenna and array design or evaluation are also included.


Antenna Magus Learning Edition makes design capabilities for 12 popular antenna types available and can generate high-quality simulation models of these designs. It can also be used to synthesize basic antenna arrays and includes a selection of useful utilities. All simulation models generated using Antenna Magus Learning Edition are fully compatible with CST Studio Suite and some models are also compatible with CST Studio Suite Student Edition You can download the Antenna Magus Learning Edition free of charge from the SIMULIA Community.

Join the SIMULIA Community, it's free!

Duration 1 minute 38

Simply log in with your 3DEXPERIENCE ID username and password. If you do not already have a 3DEXPERIENCE ID, you can register now . An account is free and access is instant.

The SIMULIA Community is our user forum for all those interested in simulation of structures, fluids or electromagnetic fields. You can discuss simulation with your peers, find the latest resources on SIMULIA simulation technology, get insights from experts and select from a large range of e-seminars to deepen your knowledge.

Antenna Magus Learning Resources

To get started, Antenna Magus Tutorials are available here

Antenna Magus Install instructions

Antenna Magus Learning Edition Installation Instructions & known issues

System requirements

Antenna Magus Learning Edition can be used on Windows only.

Download Issues

For download issues only (no other support for Abaqus), please use the community to contact us
