流体工程

在协作式产品开发平台中设计端到端且具备合规性的流体系统

加速开发完全合规性流体系统

流体系统旨在设计管路、管道、暖通空调等输送流体的产品，亦或是某些流体动力传输的场景。这类系统可根据不同应用场景基于不同的材料进行制造。由于材料和流体属性在制造过程中会发生变化，因此流体系统的设计受各种标准和规范的约束。这使得流体系统需要在使用环境中遵从严格的编码、分类和合规性。

3DEXPERIENCE 平台可实现管道、管路和暖通空调的生命周期管理。通过与制造过程轻松快速地集成，有助于加速创新产品的协作式交付。这也增强了管理复杂系统的能力。

利用标准化解决复杂性

由于产品/流程的复杂性不断增加，流体系统制造商采用了标准化方法。这样不仅能确保符合法规要求，还能使工程师根据经过验证的有限选项开展工作。

CATIA 3DEXPERIENCE 流体工程解决方案支持部署此类标准和规范（通过工程规范编辑器、数据设置应用以及库/目录）。现场管理员可以允许项目工程师按照与该行业相关的一系列特定标准工作。这样一来，可确保提高合规性。

综合全面的端到端协作流程

借助 2D 原理图，您可使用高效的 2D 工具轻松快速地创建图表。无论是概念框图、高级 PFD还是复杂的 P&ID，原理图工具不仅可以解决不同程度的复杂性，还能处理多学科数据对象。

将 2D 图表与 3D 设计同步

即使原理图尚未准备就绪，3D 流体工程师也可以尽早开始工作，从而节省时间。在适当的成熟度里程碑阶段，可以同步进行 2D 和 3D 设计，以确保完整性和可追溯性。

利用自动化和优化提升 3D 设计功能

流体三维系统设计工具有助于工程师实现设备布局并高效的创建流体网络。强大的几何图形功能和可靠的合规机制有助于他们实现目标。此外，设计自动化还有助于提高生产力并减少错误。

为制造做好准备

设计之旅并不止步于 3D 设计，您可以根据特定要求轻松生成制造所需交付成果。这些交付成果可以是管段制造图纸、装配图纸、工程 BOM、制造 BOM、报告等。

CATIA Fluid Engineering 3DEXPERIENCE 平台以的角色的形式打包，确保所有必需应用尽在掌握，助您更快上手、更高效工作。请根据您在企业中的角色选择相应的软件包。

有 3 个结果

Fluid 3D Systems Designer

Improve piping, tubing and HVAC systems quality, shorten design time and reduce material costs by optimizing the physical design of complex fluid systems

角色

Outfitting 3D Systems Designer

Engineer fluid & electrical systems and steel layout equipment while ensuring integration/synchronization in context of the overall ship or offshore platform

角色

Piping & HVAC 3D System Engineer

An integrated 3D fluid systems development environment for the physical design of piping and HVAC systems in the context of the Digital Mock-Up

角色
