先进的机电集成技术
CATELECTRE 是融合电气 (ECAD) 与机械 (CATIA) 设计的智能集成设计通道。其将 2D 功能与 3D 机械环境进行了完美结合，是构建完整机电模型的理想工具。该工具协调了 ECAD 和 CATIA 的 3D 电气设计，可创建同步两种模型的统一数字样机。其支持利用 3D 数据分析更新线束数据，并使用 ECAD 功能细节增强 CATIA 的能力。CATELECTRE 擅长在 CATIA V5 的 3D 机电空间内以交互式方式设计电气线束，并提供先进的无缝集成技术。
CATELECTRE 可根据公司设计流程灵活调整来自大多数 CAD 软件程序的现有机电模型数据，从而实现全面的双向 2D/3D 同步：
